Salient Features
- Double Walled Structure with Extremely efficient thick PUF insulation.
- Plexiglass Inner door to get inside clear view.
- Powerful Motorized Air Blower for proper Air Circulation & Temperature Uniformity.
- Handle and Heavy Duty Hinges for Proper Sealing to maintain Uniformity with Lock and Key Arrangement.
- Wire Mesh Heavy Duty Adjustable Trays for proper storage height.
- Sealed Compressor with CFC Free R 134 A / R 404 (Eco Friendly) Refrigerant.
- Safety controlling function to cut off the supply in case of overshoot and undershoot of Temperature giving Audio visual alarm.
- Chamber illumination with LED light.
- Electrical Circuit Breaker.
- Time delay for Compressor Switch on
- Overload cut off Relay for Compressor
- Castor wheel for Easy Movement of the chamber.
- Validation Protocol with IQ, OQ, PQ, Documents, Operations and Maintenance manuals.
- Works on 230V AC Single Phase 50Hz
- Microprocessor based PID, Digital Temperature Controller with Autotune option for Precise control of Temperature.
- High Quality PT-100 Temperature Sensor.
Optional Features
- PLC based Control System with 4.3”/ 7” Color touchscreen HMI.
- 21 CFR Part 11 compliance Window based communication Software for Data Management.
- Printer Interface communication with micro controller based PID controller to record set values, process values, date & time with variable print time intervals with RS -485/232 communication.
- 7 days circular chart recorder for temperature.
- Network connectivity via Ethernet.
Technical Particulars
- Capacity (Liters) : 100, 200, 300, 400, 600, 800, 1000
- Temperature Range : Ambient to -40 °C
- Temperature Accuracy : ± 0.5 °C
- Temp Uniformity : ± 3.0 °C
- GMP Model(G) : Inside S.S. 304 & Outside S.S. 304
Inside S.S. 316 & Outside S.S. 316(On Demand) - Standard Model(S) : Inside S.S. 304 & Outside mild steel powder coated
Inside S.S. 316 & Outside mild steel powder coated(On Demand)
Model/Cap. |
Dimension (W x D x H) in CM |
Max no.
|
|
“G” or “S” |
Internal |
External |
|
| PF-100 G/S | 45 X 40 X 58 | 60 X 81 X 120 | 3 |
| PF-200 G/S | 58 X 58 X 60 | 73 X 108 X 116 | 3 |
| PF-300 G/S | 58 X 58 X 90 | 73 X 108 X 170 | 4 |
| PF-400 G/S | 65 X 62 X 100 | 80 X 112 X 185 | 5 |
| PF-600 G/S | 80 X 75 X 100 | 95 X 125 X 185 | 6 |
Note: Plasma Bags will be provided as per the capacity
