Salient Features
- Double Walled Structure with Extremely efficient thick PUF Insulation.
- Plexiglass Inner door to get inside clear view.
- Powerful Motorized Air Blower for proper Air Circulation & Temperature Uniformity.
- Sealed Compressor with CFC Free R 134 A / R 404 (Eco Friendly) refrigerant.
- Humidity System with Evaporation Tray and Reservoir tank with water level arrangement.
- Safety controlling function to cut off the supply in case of overshoot and undershoot of Temperature giving Audio visual alarm
- Settable thermostat for safety, Independent of Temperature controller
- Handle and Heavy Duty Hinges for Proper Sealing with Lock and Key Arrangement
- Wire Mesh Heavy Duty Adjustable Trays for proper storage height.
- Electrical Circuit Breaker.
- Time delay for Compressor Switch on
- Overload cut off Relay for Compressor
- Castor wheel for Easy Mobility.
- Interior illumination with LED light.
- Validation Protocol with IQ, OQ, PQ, Documents, Operations and Maintenance manuals.
- Calibration of the Controlling accessories with Master Calibrator which is Certified for its accuracy with traceable reference to NABL Accredited Laboratory.
- Works on 230V AC Single Phase 50Hz
- PLC based Control system with 4.3” Color Touchscreen HMI (7” available on request).
- High Quality PT-100 Temperature Sensor.
Optional Features
- 21 CFR Part 11 Compliance Window based Communication Software for Data Management.
- Data Storage facility to record set values, process values, date & time with variable time intervals.
- Standby Refrigeration & Humidity System.
- Network connectivity via Ethernet
- Other storage conditions for Temp. & RH on request.
Note : Voltage Stabilizer not in our scope of supply.
Technical Particulars
- Capacity (Liters) : 100, 200, 300, 400, 600, 800, 1000
- Temperature Range : 20 °C to 60 °C
- Temperature Accuracy : ± 0.5 °C
- Temp Uniformity : ± 3.0 °C
- Humidity Range : 40% to 90% RH
- Humidity Accuracy : ± 2% RH
- Humidity Uniformity : ± 3% RH
- GMP Model(G) : Inside S.S. 304 & Outside S.S. 304
Inside S.S. 316 & Outside S.S. 316 (On Demand) - Standard Model(S) : Inside S.S. 304 & Outside mild steel powder coated
Inside S.S. 316 & Outside mild steel powder coated (On Demand)
Model/Cap.(Ltrs) |
Dimension (W x D x H) in CM |
Max no.
|
|
“G” or “S” |
Internal |
External |
|
| SC-100 G/S | 45 X 40 X 58 | 60 X 81 X 120 | 3 |
| SC-200 G/S | 58 X 58 X 60 | 73 X 108 X 116 | 3 |
| SC-300 G/S | 58 X 58 X 90 | 73 X 108 X 170 | 4 |
| SC-400 G/S | 65 X 62 X 100 | 80 X 112 X 185 | 6 |
| SC-600 G/S | 80 X 75 X 100 | 95 X 125 X 185 | 7 |
| SC-800 G/S | 80 X 80 X 125 | 95 X 130 X 195 | 8 |
| SC-1000 G/S | 90 X 90 X 124 | 105 X 140 X 200 | 8 |
Above capacities such as 1500L, 2000L, 3000L, etc; will be provided on Request.
