Salient features
- Double walled structure with Thick Ceramic Wool Insulation as required.
- Powerful Motorized Air Blower for proper Air Circulation & Temperature Uniformity.
- Handle and Heavy duty Hinges for Proper sealing to maintain Uniformity.
- Wire Mesh Heavy Duty adjustable Trays for proper storage height.
- Settable thermostat for safety, Independent of Temperature controller
- No Exposed Heating Elements & Terminals.
- Fixed and Adjustable Air Ventilators for Inner Chamber.
- Validation Protocol with IQ, OQ, PQ, Documents, Operations and Maintenance manuals
- Works on 230V AC Single Phase 50Hz
- Microprocessor based PID, Digital Temperature Controller with Autotune option.
- High Quality PT-100 Temperature Sensor
Optional Features
- Data Logger with RS-485/232 Communication, etc;
Technical Particulars
- Capacity (Liters) : 30,50,100, 200, 300, 400, (Other sizes on demand)
- Temperature Range : Ambient to 220 °C
- Temperature Accuracy : ± 0.5 °C
- Temp Uniformity : ± 3.0 °C
- GMP Model(G) : Inside S.S. 304 & Outside S.S. 304
Inside S.S. 316 & Outside S.S. 316 (On Demand) - Standard Model(S) : Inside S.S. 304 & Outside mild steel powder coated
Inside S.S. 316 & Outside mild steel powder coated (On Demand)
Model/Cap.(Ltrs) |
Dimension (W x D x H) in CM |
Max no.
|
|
“G” or “S” |
Internal |
External |
|
| HAO-30 G/S | 30 x 30 x 34 | 45 x 60 x 72 | 2 |
| HAO-50 G/S | 35 x 35 x 41 | 50 x 70 x 85 | 2 |
| HAO-100 G/S | 45 X 40 X 58 | 60 X 81 X 120 | 3 |
| HAO-200 G/S | 60 X 60 X 60 | 75 X 104 X 116 | 3 |
| HAO-300 G/S | 58 X 58 X 90 | 72 X 108 X 170 | 4 |
| HAO-400 G/S | 65 X 60 X 100 | 80 X 110 X 185 | 6 |
